POWER MATE 0 Maintenance manual Page 88

Maintenance manual
B–63445EN/01
3. INPUT AND OUTPUT OF DATA
73
Address
0103 Baud Rate
7: 600 9: 2400 11:9600
8: 1200 l10: 4800 12:19200 [BPS]
2) I/O cahnnel=1
Set parameters to 0111, 0112, 0113.
Seeting contens are same as 0101, 0102, 0103.
1. Select EDIT mode.
2. Execute file heading when required.
For which file the parameter is output to refer to item Explanations
(Output to a floppy).
3. Press
SYSTEM
key and soft key [PARAM] to display parameter screen.
4. Press soft key [(OPRT)] ,and soft key
.
5. Press soft key [PUNCH] and [EXEC],and the parameters are started
to be output.
1. Select EDIT mode.
2. Select the parameter display screen by
key.
3. Press the
key.
4. Execute file heading when required.
For which file the parameter is output to refer to item Explanations
(Output to a floppy).
5. While parameter, is being output, the display appears as below.
>&0001 0 0 0 0 0 0 0 0
WRITE
6. In order to stop output of data from a tape before it has finished, turn
on external reset signal ERS (bit 7 of G008).
Once data output from a tape has been stopped, it cannot be restarted.
3.2.2
Outputting CNC
Parameters
D Procedure (CRT/MDI)
D Procedure (DPL/MDI)
