POWER MATE 0 Maintenance manual Page 119

Maintenance manual
4. INTERFACE BETWEEN NC AND PMC
B–63445EN/01
104
N0123
SUB 50 PSGNL
3 Relay search
Entering <address number> then searches for the relay
including the entered address.
(Example)
,
N0105
AND X1000.2
4 Relay coil search
Entering
, <address number>, then searches for the relay
coil including the entered address.
(Example)
, ,
N0187
WRT. NOT Y1000.5
5 Functional instruction search
Entering
, <functional instruction number>, then searches
for the entered functional instruction.
(Example)
, ,
N0123
SUB 50 PSGNL
NOTE
1 Relay search, relay coil search, and functional instruction
search are started from the current screen. If the relay, relay
coil, or instruction is not found by the end of the ladder
program, search is performed from the beginning of the
ladder program to the step at which search was started. If
still not found, ”NOT FOUND” is displayed.
2 Display of some instructions may differ from that for FAPT
LADDER.
N0105 NOT FOUND
AND X1000.2
P–G, personal–computer FAPT LADDER Ladder mnemonics editing
(a) RD.NOT.STK
(b) TMR timer–number
(c) DEC code–signal–address
(PRM) decode–instruction
RD.N.STK
SUB 03 TMR
P001 timer–number
SUB 04 DEC
P001 code–signal–address
P002 decode–instruction
The above also applies when modifying the ladder mnemonics.
