POWER MATE 0 Maintenance manual Page 130

Maintenance manual
B–63445EN/01
4.INTERFACE BETWEEN NC AND PMC
115
Symbol PMC addressSignal name
+J1, +J2, –J1, –J2
Feed axis direction select signal G100#0, #1,
G102#0, #1
+J1O, –J1O, +J2O,
–J2O
Manual feed F081#0 to #3
:
JV0 to
:
JV15 Manual feedrate override signal G010, G011
:
JV0O to
:
JV15O Jog feedrate setting signal F079, F080
K0 to K9, KMNS,
KPRD, KNO, KSLH,
KEOB, KCAN, KALT,
KINS, KDLT, KINP,
KWRT, KRED, KPOS,
KPRG, KVAR, KPRM,
KALM, KDWN, KUP,
KP, KQ, KH, KO, KN,
KG, KR, KX, KF, KM,
KS, KT, KSHRP
Key data reference function by PMC F210 to F218
KEY1, KEY2, KEY3,
KEY4
Memory protection key G046#3 to #6
KEYO Program protect signal (software operator’s panel) F075#6
M00 to M31 M function code signal F010 to F013
MZRN Manual reference position return check signal F004#5
MA Ready signal F001#7
MMEM Automatic operation (MEMORY) check signal F003#5
MD1 ,MD2, MD4 Mode select signal G043#0 to #2
MD1O ,MD2O, MD4O Software operator’s panel signal F073#0, F073#1,
F073#2
MEDT Memory edit (EDIT) check signal F003#6
MF M code output end signal F007#0
MFIN M function end signal G005#0
MH Manual handle or step feed (HANDLE/STEP) check signal F004#1
MI1, MI2 Mirror image signal G106#0, #1
MJ Jog feed (JOG) check signal F003#2
MLK Machine lock signal G044#1
MLKO Machine lock signal (software operator’s panel) F075#4
MMDI Manual data input (MDI) check signal F003#3
MP1, MP2 Incremental feed signal G019#4, #5
MP1O, MP2O Incremental feed signal (software operator’s panel) F076#0, #1
MRMT Tape command (RMT) check signal F004#4
MVD1, MVD2 Moving direction signals F106#0, #1
OP Automatic operation signal F000#7
