POWER MATE 0 Maintenance manual Page 213

Maintenance manual
APPENDIX
C. DATA INPUT/OUTPUT TO AND
FROM A MEMORY CARD
B–63445EN/01
200
No. Message Explanation
5101 MEMORY CARD NOT CONNECTED No memory card is connected to the unit. Before performing input/op-
utput, a memory card.
5102 WRITE PROTECTED The memory card is write-protected. Before writing data to the card,
release write protection.
5103 MEMORY CARD READ/WRITE ER-
ROR
(Seve) Data cannot be written to the memory card.
(Restoration) The memory card does not contain correct data.
The card may be damaged. Retry input/output with another memory
card.
5104 EMERGENCY STOP RELEASED Emergency stop was released during input/output to or from a memory
card. Place the system in the emergency stop state, then retry input/
output.
5105 LADDER READ ERROR An alarm was issued during input of ladder data from a memory card.
Retry input of ladder data.
5106 INSUFFICIENT MEMORY CARD
CAPACITY
The capacity of the memory card is insufficient to save the data. Insert
a memory card with sufficient memory, then retry.
5107 IMPROPER MEMORY The data stored in a memory card is not appropriate for the unit. Insert
a memory card holding appropriate data, then retry.
5109 PMC COMMUNICATION ERROR A PMC communication error occurred during input/output to or from a
memory card. Retry input/output.
C.4
ERROR CODES
