POWER MATE 0 Maintenance manual Page 94

Maintenance manual
B–63445EN/01
3. INPUT AND OUTPUT OF DATA
79
1. Set the emergency stop state.
2. Press
OFFSET
SETTING
key and soft key [SETTING] to select the SETTING
screen.
3. Confirm that PARAMETER WRITE=1.
4. Press
SYSTEM
key and soft key [PMC].
5. Press soft key [PMCPRM] and soft key [KEEPRL].
6. Set the cursor to K17 and set bit 1 to 1.
× × ×× × ×
1
×
INPUT
.
× means the setting value which is before input.
7. Press
key and key.
8. Press soft key [I/O] and set the parameters required for I/O.
Item selection cursor displays the next item after an item is set.
9. In CHANNEL item , press
1
INPUT
to select channel 1.
10.In DEVICE item, press [FDCAS] key.
11.In FUNCTION item, press soft key [READ] to input data.
12.Press soft key [EXEC] and the PMC parameters are started to be input.
13.After data has been read, turn off power and turn it on.
1. Set the emergency stop state.
2. Press
key several times and soft key to select the SETTING
screen.
3. Confirm that DWE=1.
4. Press
key several times and set diagnosis screen (@).
5. Press
then set the file number.
6. Press
and the PMC parameters are started to be input.
7. After data has been read, turn off power and turn it on.
3.2.10
Inputting PMC
Parameters
D Procedure (CRT/MDI)
D Procedure (DPL/MDI)
