Data stored in Power Mate memory can be output to a memory card by
following the procedure below.
(1) Place the Power Mate in EDIT mode.
(2) Place the system in the emergency stop state.
(3) Press the <PRGRM> display button to display the program display
screen.
(4) Insert the memory card in the CNC.
(5) Enter address <M>.
(6) Select the [OPERATION], [→], and [PUNCH] soft keys, then press
[EXEC].
(When the DPL/MDI is used, press the <WRITE> key.)
All data in the Power Mate memory is then output.
Data can be input from a memory card to Power Mate memory by
following the procedure below.
- Inputting all data
(1) Place the Power Mate in either EDIT or MDI mode.
(2) Place the system in the emergency stop state.
(3) For both paths, set setting parameter [parameter write enable] to 1.
(When the DPL/MDI is used, set [PWE] to 1.)
(4) Press the <PRGRM> display boutton to display the program display
screen.
(5) Insert the memory card in the Power Mate.
(6) Enter address <M>.
(7) Select the [OPERATION] [→] and [READ] soft keys, then press
[EXEC].
(When the DPL/MDI is used, press the <READ> key.)
All data is then read into the CNC memory.
- Inputting specific data
(1) Place the Power Mate in either EDIT or MDI mode.
(2) Place the system in the emergency stop state.
(3) Set setting parameter [parameter write] to 1.
(When the DPL/MDI is used, set [PWE] to 1.)
(4) Press the <PRGRM> display button to display the program display
screen.
(5) Insert the memory card in the Power Mate.
(6) Enter address <M>.
C.3
OPERATION
C.3.1
Outputting Data to a
Memory Card
C.3.2
Inputting Data from a
Memory Card
