Fast Ethernet Board/Fast Data Server Operators manual Page 357

Operators manual

Page of 532

/ 532

B-63644EN/02 VI. MAINTENANCE 1.Series 16i/18i/21i, Power Mate i MAINTENENCE INFORMATION

- 343 -

Symbol Meaning

P Waiting for a request from the CNC

D Data being processed

W Waiting for data reception

S Data being transmitted

K Subtask being activated

REMOTE DIAG

X Not executed yet

P Waiting for a request from the CNC

D Data being processed

W Waiting for data reception

S Data being transmitted

FACTOLINK

N Not executed yet

DATASERVER D Data being processed(NOTE)

#1,#2 W Waiting for data processing(NOTE)

D Data being processed(NOTE)

W Waiting for data processing(NOTE)

FTP SERVER

Number

Number of sockets currently

connected

NOTE

The state switches between "Data being processed"

and "Waiting for data processing" even if actual

communication is not performed.
