FAST Ethernet Board / FAST DATA SERVER
OPERATOR’S MANUAL
A
bout the error messages
B-63644EN/02-6
Error codes about Ethernet communication
Error
Code
mean
202 The specified file or directory does not exist.
224 Too many Ethernet connections were used or the
Ethernet function was not initialized.
Check the states of the connection and the settings
of the basic parameters such as the IP address.
254 The connection was turn off. (Note)
257 The connection was not connected. (Note)
258 The connection was already disconnected. (Note)
260 The connection was turn off by timeout. (Note)
261 The connection was denied.
265 The route for the specified host computer was not
detected.
Check that the specified host computer exists
actually or the settings of the IP address or subnet
mask was corrected.
Note
An electrical noise causes resetting the connection with PC. If the
connection is reset unexpectedly, check the electrical noise.
