8. CNC DISPLAY UNIT WITH PC FUNCTIONS
189
A02B–0236–C132#EC :
FA Full Keyboard (English) for 12.1” LCD type
A08B–0082–C150#JC :
FA Full Keyboard (Japanese) for 15.0” LCD type
A08B–0082–C150#EC :
FA Full Keyboard (English) for 15.0” LCD type
A08B–0082–C151#JC :
FA Full Keyboard (Japanese) for 15.0” LCD type (punch panel
built–in)
A08B–0082–C151#EC :
FA Full Keyboard (English) for 15.0” LCD type (punch panel
built–in)
NOTE
1 Commercial typewriter–style keyboards are prone to
compatibility problems with personal computers to some
degree. It is not guaranteed that the intelligent terminal type
2 can operate with every commercial typewriter–style
keyboard. Machine tool builders are requested to check the
operability of the typewriter–style keyboards they select.
Keep in mind that general commercial typewriter–style
keyboards are neither dust–proof nor moisture–resistant.
2 If an FA typewriter–style keyboard is incorporated into the
system, clamp its cable at a point as close to it as possible
so that the weight of the cable is not applied directly to the
connector.
