9. CONNECTION TO FANUC I/O Link

B–63523EN/03

258

Installation specifications

Ambient temperature During operation 0°C to 58°C

During storage and transportation –20°C to 60°C

Temperature change Max. 1.1°C/min.

Relative humidity Normal : 75% or less

Short term (1 month or less) : 95% or less

Vibration During operation : 0.5 G or less

Environment Ordinary machining factory environment

(Special consideration is required when installing the

module in a dusty location or where highly concen-

trated cutting lubricant or organic solvent is used.)

Other requirements (1) Install the I/O module in a fully enclosed cabinet.

Ordering specifications

Item Specification Remarks

Operator’s panel I/O

module

A20B–2002–0470 General–purpose DI: 16 points

Matrix DI: 56 points

DO: 56 points

MPG interface is supported.

Fuse

(replacement part)

A03B–0815–K001 1 A

Module specifications

Item Specification Remarks

General–purpose DI 16 points 24–V input

Matrix DI 56 points (8 7) 5–V input

DO points 56 points 24 V source type output

CNC interface FANUC I/O Link

connection

Up to 16 modules can be

connected as CNC slaves. Or, a

maximum of 1024 points can be

supported on both the input and

output sides.

MPG interface Max. 3 units MPG interface can be used only

for the i series CNC.

9.5.9

Specifications
