F. MEMORY CARD INTERFACE
B–63523EN/03
572
Purpose
Vendor Specification Capacity
For Data
Input/Output
For automatic
operation
from PCMCIA
port.
For Data
server
Remarks
HB286008A3 8MB Available Available — No production
HB286015A3 15MB Available Available — No production
HB286030A3 30MB Available Available — No production
HB286045A3 45MB Available Available — No production
HB286075A3 75MB — — Available No production
HB286090A3 90MB — — Available No production
HB286150A3 150MB — — Available No production
HB289016A4 16MB Available Available —
HB289032A4 32MB Available Available —
HITACHI
HB289048A4 48MB Available Available —
HB289080A4 80MB NG Available Available
HB289096A4 96MB NG Available
HB289160A4 160MB NG Available Available
HB288096A5 96MB NG Available Available
HB288160A5 160MB NG Available Available
HB288320A5 320MB NG Available Available
HB288640A5 640MB NG Available Available
HB2881000A5 1GB NG Available Available
BN–012AB 12MB Available Available —
MATSUSHITA
BN–020AB 20MB Available Available —
BN–040AB 40MB Available Available —
SDP3B–4 4MB Available Available —
SDP3B–8 8MB Available Available —
SDP3B–16 16MB Available Available —
SDP3B–20 20MB Available Available —
SDP3B–32 32MB Available Available —
SanDisk
SDP3B–40 40MB Available Available —
SDP3B–64 64MB NG Available —
SDP3B–220 220MB NG Available Available
SDP3B–280 280MB NG Available Available
SDP3B–350 350MB NG Available Available
SDP3B–440 440MB NG Available Available
