Series 16i/160i/160is/18i/180i/180is/21i/210i/210is - Model B Connection manual (Hardware) Page 461

Connection manual (Hardware)
B–63523EN/03
14. CONNECTION FOR Series 160is/180is/210is
445
Recommended cables (for fixed parts)
Manufacturer Specification Remark
Furukawa Electric Co., Ltd. DTS5087C–4P Twisted wires
Nissei Electric Co., Ltd. F–4PFWMF Single–wire cable
NOTE
These recommended cables for fixed parts must not be
used for movable sections. Be sure to use the following
recommended cables for movable sections.
Recommended cable (for movable sections)
Manufacturer Specification Remark
Oki Electric Cable
Co., Ltd.
AWG26 4P TPMC–C5–F(SB) Dedicated to FANUC products
Cable specification (FANUC original product, with no connector)
Drawing number: A66L–0001–0453
Manufacturer: Oki Electric Cable Co., Ltd.
Specification
– Electrical characteristic: Complying with EIA/TIA 568A
categories 3 and 5
The length of the cable to the hub must be kept within 50 m
because of its attenuation performance.
– Structure: Common–shield braided cable with drain wire
The conductors of the cable are AWG26 annealed–copper
strand wire, with a sheath 0.8 mm thick and an outer diameter
of 6.7"0.3 mm
– Fire resistance: UL1581 VW–1
– Oil resistance: As per FANUC’s internal standard (Equivalent
to conventional oil–resistant electrical cable)
– Flex resistance: Million or more bending cycles with a bending
radius of 50 mm (U–shaped bend test)
– UL style No.: AWM20276 (80_C/30V/VW–1)
NOTE
Use the TM21CP–88P(03) connector made by Hirose
Electric Co., Ltd. to this cable.
About cable assemblies
Oki Electric Cable Co., Ltd. can offer a cable assembly that uses the
TM21CP–88P(03) connector made by Hirose Electric Co., Ltd. To
get this cable assembly, negotiate directly with the manufacturer on its
specifications (cable length, shipping test, package, etc.).
