9. CONNECTION TO FANUC I/O Link
397
Temperature
Around a unit
At operation 0_C to 55_C
Storing or transporting –20_C to 60_C
Temperature
variance
Max. 1.1_C/min
Humidity Normally 75% or less (Relative humidity)
Short time(Within one month) 95% or less (Relative humidity)
Vibration Operating 0.5G or less
Atmosphere Normal FA atmosphere(Consult us when using the system under environments with higher degree of dust, coolant, or
organic solution.)
Name Specification Note
Machine operators panel Main panel A A02B–0236–C230 Symbol key
Machine operators panel Main panel B A02B–0236–C231 Symbol key
Machine operators panel Main panel A1 A02B–0236–C240 English key
Machine operators panel Main panel B1 A02B–0236–C241 English key
Machine operators panel Sub panel A A02B–0236–C232
Machine operators panel Sub panel B A02B–0236–C233
Machine operators panel Sub panel C A02B–0236–C234
Machine operators panel Sub panel B1 A02B–0236–C235
Machine operators panel Sub panel C1 A02B–0236–C236
Adapter plate B
(Note)
A02B–0236–J411 Backup unit
(A02B–0269–H051)
Set of transparent key tops A02B–0236–K170 55 key tops
Set of blank key tops A02B–0236–K171 55 key tops
Set of symbolic key tops A02B–0236–K172 With laser marking
(34 symbol key tops + 21 blank key tops)
Fuse(Spare part) A03B–0815–K001 1A
NOTE
Adapter plate B is unnecessary when Main panel B or B1 are used,
9.13.7
Specifications
9.13.7.1
Environmental
requirement
9.13.7.2
Order specification
