9. CONNECTION TO FANUC I/O Link

B–63523EN/03

260

DO (output signal) specifications

Maximum load current in ON state 200 mA or less

(including momentary current)

Saturation voltage in ON state Max. 1 V (when load current is 200 mA)

Withstand voltage 24 V +20% or less

(including momentary values)

Leakage current in OFF state 20 mA or less

Delay Driver delay: Max. 50 ms

The time required for I/O Link transmission

between the CNC and I/O module (max. 2

ms + CNC ladder scan cycle) must also be

taken into account.

NOTE

Ensure that the maximum current per DOCOM pin (DO

power supply pin) does not exceed 0.7 A.
