B–63523EN/03

D. OPTICAL FIBER CABLE

553

Table D.1 Standard cable length

Internal cord type cable

External cable

A66L–6001–0023# A66L–6001–0026#

Specification Length Specification Length

L150R0 0.15 m L1R003 1.0 m

L300R0 0.3 m L2R003 2.0 m

L500R0 0.5 m L3R003 3.0 m

L1R003 1.0 m L5R003 5.0 m

L2R003 2.0 m L7R003 7.0 m

L3R003 3.0 m L10R03 10.0 m

L5R003 5.0 m L15R03 15.0 m

L7R003 7.0 m L20R03 20.0 m

L10R03 10.0 m L30R03 30.0 m

L50R03 50.0 m

L100R03 100.0 m

L200R03 200.0 m

2. Cable selection

D Always use an external cable (A66L–6001–0026#) when the cable

is to be laid outside the power magnetics cabinet or main unit

cabinet, where it may be pulled, rubbed, or stepped on.

D Use an external cable when part of the cabling is to be subject to

movement. For example, when connecting a portable

operation

pendant box to the power magnetics cabinet, the use of an external

cable is desirable because the cable is likely to be bent, pulled, or

twisted repeatedly even though frequent system operation is not

expected. However, the force likely to be applied when the cable

is installed or moved for maintenance purposes does not need to be

taken into consideration.

D Use an external cable in locations where sparks or flame are a

danger. Although the internal cord type cable

(A66L–6001–0023#) is covered by nonflammable resin, the cover,

if exposed to frame for a long time, may melt, allowing the fiber

cable inside to burn.

D Use an external cable when the cable is expected to be pulled with

considerable force during installation (the force applied to the cable

must be within the specified tensile strength limit at all times). For

example, even though installing a cable in a cable duct can be

regarded as internal cabling, a cable of the appropriate type must

be selected according to the tensile force to be applied to the cable

during installation.

D Both the internal cord type and external cables have the same oil

and heat resistance properties.
