B–63523EN/03

9. CONNECTION TO FANUC I/O Link

351

Contact capacity 30 VDC. 16 mA or more

Leakage current between

contacts when opened

1 mA or less (26.4 V)

Voltage decrease between

contacts when closed

2 V or less (including voltage drop in the cable)

Delay The receiver delay is 2 ms (maximum). In addition,

[I/O Link transfer time between CNC and machine

operator’s panel (2 ms maximum)] + [ladder scan

period (depending on CNC)] must be considered.

Maximum load current

when ON

200 mA or less including momentary variations

Saturation voltage when

1 V (maximum) when the load current is 200 mA

Withstand voltage 24 V +20% or less including momentary variations

Leakage current when OFF 20 µA or less

Delay time The driver delay is 50 s (maximum). In addition,

[I/O Link transfer time between CNC and I/O

module (2 ms maximum)] + [ladder scan period

(depending on CNC)] needs to be considered.

NOTE

The maximum current for each of the DOCOM power supply

pins for the DO signals must not exceed 0.7 A.

General–purpose DI

signal specifications

General–purpose DO

signal specifications
