8. CNC DISPLAY UNIT WITH PC FUNCTIONS
191
1 STD0 11 :STB
2 STD1 12 0V
3 STD2 13 :AFD
4 STD3 14 0V
5 STD4 15 :INIT
6 STD5 16 0V
7 STD6 17 :SLIN
8 STD7 18 :ACK
9PE 19:ERROR
10 SLCT 20 BUSY
JD9
(PCR–E20MD)
1 :STB 19 0V
2 STD 20 0V
3 STD1 21 0V
4 STD2 22 0V
5 STD3 23 0V
7 STD5 25 0V
6 STD4 24 0V
8 STD6 26 0V
9 STD7 27 0V
10 :ACK 28 0V
11 BUSY 29 0V
12 PE 30 0V
13 SLCT 31 :INIT
14 :AFD 32 :ERROR
15 33 0V
16 0V 34
17 FG 35
18 36 :SLIN
CNC display unit with PC functions
Example) Printer
1) Recommended cable conductor
A66L–0001–0284#10P: 10 pairs of 0.08 mm
2
wires
2) Recommended cable–end connectors (JD9 side)
PCR–E20FA (Honda Tsushin Kogyo Co., Ltd.)
FI30–20S (Hirose Electric Co., Ltd.)
FCN–247J020–G/E (Fujitsu Limited)
52622–2011 (Molex Japan)
NOTE
1 The interface on the printer side shown above is only an example. Design an interface cable
according to the specification of the printer with which it is used.
2 Commercial printers are prone to compatibility problems with personal computers to some
degree. It is not guaranteed that intelligent terminal type 2 can operate with every commercial
printer. Machine tool builders are requested to check the operability of the printers they select.
Keep in mind that general commercial printers are neither dust–proof nor moisture–resistant.
8.7.7
Centronics Parallel
Port
