B–63523EN/03

12. HIGH–SPEED SERIAL BUS (HSSB)

425

WARNING

Before starting to mount or remove a personal computer

interface board, switch off the personal computer and its

peripheral devices, and disconnect their power supply

cables. Otherwise, there is a serious danger of electric

shock.

(1)Remove the covering plate of ISA extension slot on the personal

computer.

(2)Set the I/O base address of the interface board (in only case of ISA

type).

Before mounting the interface board of ISA type, set the I/O address not

to conflict with the I/O address areas that are used by the personal

computer and other ISA extension boards. Set the I/O address not to

conflict with each other in case that two or more interface boards for the

personal computer are used (HSSB multi–connection).

The interface board of PCI type is setting free.

(3)Insert the interface board for the personal computer to the ISA

connector tightly.

(4)Screw the plate of interface board to the computer.

(5)Confirm connection (in only case of HSSB multi–connection)

Confirm following items for installing drivers of HSSB interface

board in case of HSSB multi–connection.

D In case of ISA type

I/O port address set to HSSB channel

Correspondence between HSSB channel and CNC

D In case of PCI type

PCI slot number which HSSB board is mounted (slot number

is marked to PCB normally).

Correspondence between HSSB channel and CNC

(6)Restore the covering plate.

NOTE

Do not touch the leads running to the card edge of the

interface board (that match with connectors).

12.6

PROCEDURE FOR

INSTALLING

PERSONAL

COMPUTER

INTERFACE BOARDS
