Series 16i/160i/160is/18i/180i/180is/ Descriptions Page 413

Descriptions
B–63522EN/02
27. DISPLAYING AND SETTING DATA
NC FUNCTION
385
Display item and setting items
The item related to the embedded Ethernet function is displayed.
Item Description
MAC ADDRESS Embedded Ethernet MAC address
Set the TCP/IP–related items of the embedded Ethernet.
Item Description
IP ADDRESS Specify the IP address of the embedded Ethernet.
(Example of specification format: ”192.168.1.1”)
SUBNET MASK Specify a mask address for the IP addresses of the net-
work.
(Example of specification format: ”255.255.255.0”)
ROUTER IP
ADDRESS
Specify the IP address of the router.
Specify this item when the network contains a router.
(Example of specification format: ”192.168.1.254”)
Make settings related to the FTP file transfer function.
Settings for up to three host computers can be made.
Item Description
PORT NUMBER Specify a port number to be used with the FTP file transfer
function.
An FTP session is used, so that ”21” is to be specified
usually.
IP ADDRESS Specify the IP address of the host computer.
(Example of specification format: ”192.168.1.150”)
USERNAME Specify a user name to be used for logging in to the host
computer with FTP.
(Up to 31 characters can be specified.)
PASSWORD Specify a password for the user name specified above.
Be sure to set a password.
(Up to 31 characters can be specified.)
LOGIN DIR Specify a work directory to be used when logging in to the
host computer.
(Up to 127 characters can be specified.)
Display item related to
the embedded Ethernet
function
Embedded Ethernet
TCP/IP setting items
FTP file transfer setting
items
Previous page
Next page
