D. EXTERNAL DIMENSIONS OF EACH UNIT
513
D
EXTERNAL DIMENSIONS OF EACH UNIT
(Outline Drawings of the i Series CNC with a LCD–mounted Type Panel)
Outline drawing title Specification drawing number Figure
Series 16i/18i/21i 7.2″ STN A02B–0281–B500,B502,B503,B504 A02B–0281–H124 Fig.U1
control unit monochrome LCD
panel
A02B–0283–B500,B502,B503,B504 A02B–0281–H124
panel
A02B–0297–B500,B502,B503,B504 A02B–0281–H124
A02B–0285–B500,B502,B503,B504 A02B–0281–H124
8.4″ TFT color A02B–0281–B500,B502,B503,B504 A02B–0281–H123 Fig.U2
LCD panel
A02B–0283–B500,B502,B503,B504 A02B–0281–H123
A02B–0297–B500,B502,B503,B504 A02B–0281–H123
A02B–0285–B500,B502,B503,B504 A02B–0281–H123
9.5″ STN A02B–0281–B500,B502,B503,B504 A02B–0281–H122 Fig.U3
monochrome LCD
panel
A02B–0283–B500,B502,B503,B504 A02B–0281–H122
panel
A02B–0297–B500,B502,B503,B504 A02B–0281–H122
A02B–0285–B500,B502,B503,B504 A02B–0281–H122
10.4″ TFT color A02B–0281–B500,B502,B503,B504 A02B–0281–H120,H121 Fig.U4
LCD panel
A02B–0283–B500,B502,B503,B504 A02B–0281–H120,H121
A02B–0297–B500,B502,B503,B504 A02B–0281–H120,H121
A02B–0285–B500,B502,B503,B504 A02B–0281–H120,H121
(Outline Drawings of the i Series CNC with a Stand–alone Type Unit)
Series 16i/18i/21i and Series 160i/180i/210i control units A02B–0281–B801, B803,
A02B–0283–B801, B803,
A02B–0297–B801, B803,
A02B–0285–B801, B803
Fig. U6
10.4″/9.5″ LCD unit A02B–0281–C071, C081, C061, C066 Fig. U7
7.2″ LCD/MDI unit (Unit applied to display link) A02B–0166–C261#TR, R, TS, S Fig. U8
7.2″ monochrome LCD unit (Unit applied to display link) A02B–0166–C251 Fig. U9
MDI unit (for 7.2″ LCD) (Unit applied to display link) A02B–0166–C210#TR, TS, R, S Fig. U10
Detachable 7.2″ LCD/MDI unit (Unit applied to display link) A02B–0166–C271#TR, TS, R, S Fig. U11
