1. Fanuc
  2. Series 16i/160i/160is/18i/180i/180is/

Series 16i/160i/160is/18i/180i/180is/ Descriptions Page 492

Descriptions
B–63522EN/02
2. CONVERSATIONAL AUTOMATIC
PROGRAMMING FUNCTION FOR
LATHES
AUTOMATIC PROGRAMMING
FUNCTION
464
Programs created conversationally are listed on the program directory
screen. The user can choose from these programs.The figure produced by
a specific program can be displayed in a window for checking.
EDIT THE PROCESSING PROGRAM *** PROGRAM MENU *** [CAP. : HEAD–L]
(REST NO. OF PROGRAM 23 PCS.)
(REST NO. OF PROCES 236 PCS.)
PRG. NO NAME CYCLE TIME CREATED MODIFIED
0194:(EXEC)BOZAI T 1994/05/26 11:19
4257: 1994/05/25 16:55
PROGRAM NO. =
INITAL SET FC2
PROC(01) BA T0101
PROC(01) BA T0101
PROC(02) DRILLING T0808
PROC(03) BAR INNER END HEAD–L ROUGH T0303
PROC(03) BAR INNER END HEAD–L FIN T0303
*** PLOTTING OF PART FIGURE ***
RETURN
Tool data, cutting condition data, and pre–tool data can be input easily by
following the instructions displayed on the screen.Once data is input,
necessary data for machining is determined automatically.
HEAD–L HEAD–R
[CAP. : HEAD–L]
101#L OUTER T0101 RN 0.800 AC 90 AN 60 TW 30.000
102#R OUTER T0101 RN 0.800 AC 90 AN 60 TW 30.000
151#L INNER T0303 RN 0.800 AC 90 AN 60 TW 20.000
*** TOOL DATA(1) ***
TOOL–ID NO @NO. 101
TOOL TYPE OUTER (HEAD–L)
TOOL DIREC
ROUGH/FIN COMMON
OUTPUT T 0101
REVOLUT.–D NORMAL
NOSE–RADIS RN= 0.800
CUTTING EDG AC= 90
NOSE ANGLE AN= 60
NOSE WIDTH TW= 30.000
IMGNRY NOS TD= 3
TL MATRIAL TM= CARBID
<
AC
RN
AN
TW
MENU TOOL TOOL
RETURN LIST FIGURE
Program directory
screen
Tool/cutting condition/
pre–tool automatic
determination
Previous page
Next page
