Series 16i/160i/160is/18i/180i/180is/ Descriptions Page 468

Descriptions
35. PERSONAL COMPUTER
FUNCTION
B–63522EN/02
NC FUNCTION
440
Personal computer software for 160i/180i/210i
Item
Specification Remarks
Operating
system
WindowsR 95
Windows NTR4.0
WindowsR 2000 *1, *5
Expansion
library
FOCAS1 *4
CNC basic operation package Option
Milling animation function Option
CNC screen display function Option
Package
software
Ladder editing package Option
software
DNC operation management
package
Option
Machining status monitor pack-
age
Option
Development
tools
Visual C++R *6
Visual BasicR *6 *9
Microsoft Corp.
Microsoft Corp.
NOTE
*1 Intel, Pentium are registered trademarks of Intel
Corporation. Celeron is trademark of Intel Corporation,
MIcrosoft, Windows, Windows NT, VIsual C++, Visual
Basic are registered trademarks of Microsoft Corporation.
Each companie’s name and product’s name is the
trademark or registered trademark.
*2 A special driver is necessary to display 16 or more colors.
*3 Extension Board for IBM PC should be prepared by MTB.
*4 FOCAS1: F
ANUC Open CNC API Specifications version
1
*5 Some of the hardware/software products are not available
in WindowsR 2000 at present.
*6 An LCD is created using high–precision processing
technology. On the LCD, some points may be always on;
others may be always off. This status is caused due to the
structure of the LCD and indicates no failure.
