Series 16i/160i/160is/18i/180i/180is/ Descriptions Page 49

Descriptions
B–63522EN/02
2. LIST OF SPECIFICATIONS
GENERAL
21
Item
Series 21i
Series 210i
Series 210is
Series 18i
Series 180i
Series 180is
Series 16i
Series 160i
Series 160isSpecifications
TBMBTBMBMB5TBMB
General–purpose switch on
software operator’s panel
l l l l l l l
Expansion of general–purpose
switch on software operator’s
panel
”General–purpose switch on
software operator’s panel” func-
tion is necessary
l l l l l — —
Touch panel l l l l l l l
External touch panel interface l l l l l l l
English f f f f f f f
Japanese (kanji) l l l l l l l
German/French l l l l l l l
Italian l l l l l l l
Chinese l l l l l l l
Display language
Spanish l l l l l l l
Korean l l l l l l l
Portuguese l l l l l l l
Hungarian l l l l l l l
Dutch l — l l — l —
Data protection key 4 types f f f f f f f
Screen clear *1 f f f f f f f
Data input/output
Reader/punch interface
(channel 1)
l l l l l l l
Reader/punch interface
Reader/punch interface
(channel 2)
l l l l l l l
Simultaneous input/output op-
eration
Only at 1–path l — l l — — —
Remote buffer Only at 1–path l l l l l l l
High–speed remote buffer A Only at 1–path l l l l l l l
High–speed remote buffer B Only at 1–path l — l l — l —
Data server Only at 1–path *1 l l l l l l l
External I/O device control l l l l l l l
DNC1 control
Part program uploading/down-
loading, CNC data read/write,
PMC data transfer, memory op-
eration control, etc.
l l l l l l l
DNC2 control
For one–path system only Part
program uploading/download-
ing, CNC data read/write, PMC
data transfer, memory operation
control, etc.
l l l l l l l
Modem card control *1 f f f f f f f
External tool compensation l l l l l l l
External message l l l l l l l
External machine zero point
shift
l l l l l l l
External data input Including three items above l l l l l l l
External key input f f f f f f f
External programming f f f f f f f
Note) The items marked with *1 to *8 (including *1–1, *1–2, and *2–1) have notes added. These notes are pro-
vided at the end of this chapter.
