Conversional Automatic Programming (CAP) Operators manual Page 132

Operators manual
B–61804E–2/05
3. EXECUTION OF
SYMBOLIC FAPT
PROGRAMMING AND
OPERATION BY SYMBOLIC FAPT
121
CUTTING SPEED V = Cutting speed . . . . . .
(m/min or feet/min)
FEED RATE F1 = Feedrate in roughing . . . . . . . . . . .
(mm/rev or inch/rev)
F2 = Feedrate in finishing
(mm/rev or inch/rev)
MAX RPM N = Maximum spindle speed (rpm). . . . . . . . . . . .
NOTE
If necking is specified, the operator is not prompted to enter
TW, TB, and F2.
When a versatile tool is selected (TP = 11)
TOOL OFFSET NO. TM= Tool offset number (tool offset. . . .
number for each cutting area)
TOOL OFFSET NO.2 TM2=Tool offset number 2 (tool offset. . .
number 2 for each cutting area)
ROUGH TYPE TP1 =Type of roughing (1, 2, or 3). . . . . . . . .
FINISH TYPE TP2 =Type of finishing (1, 2, or 3). . . . . . . . .
CLEARANCE C = Clearance (mm or inch). . . . . . . . .
FINISH. ALLOWANCE TW = Finishing allowance for width.
(mm or inch)
TB = Finishing allowance for depth
(mm or inch)
DEPTH OF CUT D = Depth of each cut in pecking . . . . . . .
(mm or inch)
CUTTING SPEED V = Cutting speed . . . . . .
(m/min or feet/min)
FEED RATE F1 = Horizontal feedrate in roughing. . . . . . . . . . .
(mm/rev or inch/rev)
F2 = Approach feedrate in roughing
(mm/rev or inch/rev)
F3 = Feedrate in finishing
(mm/rev or inch/rev)
MAX RPM N = Maximum spindle speed (rpm). . . . . . . . . . . .
[ROUGHING OF GROOVE]
When a grooving tool is selected (roughing type is 1)
TOOL OFFSET NO. TM = Tool offset number (tool offset. . . .
number for each cutting area)
TOOL OFFSET NO.2 TM2=Tool offset number 2 (tool offset. . .
number 2 for each cutting area)
PECKING ON/OFF PE = Pecking . . . . .
(0: Not executed, 1: Executed)
DEPTH OF CUT D = Depth of each cut in pecking . . . . . . .
(mm or inch)
RETURN AMOUNT U = Distance of each retraction in. . . .
pecking (mm or inch)
