Conversional Automatic Programming (CAP) Operators manual Page 695

Operators manual
B–61804E–2/05
A. SETTING DATA,
SYSTEM PARAMETER, MTF
APPENDIX
45
Parameter
No.
Description
Initial
value
Format
1351 Integer 68 C–axis clamping M code
1352 Integer 69 C–axis unclamping M code
1353 Integer 1 Cutting along the X axis in the interpolation rigid tapping cycle
1354 Integer 2 Cutting along the Y axis in the interpolation rigid tapping cycle
1355 Integer 6 Tool calling M code
1360 Integer 83. Drilling cycle dwell off Front face
1376 Integer 85. Boring cycle Front face
1377 Integer 89. Boring cycle Side face
1380 Integer 107. Cylindrical interpolation start/cancel
1381 Integer 112. Polar coordinate interpolation start
1382 Integer 113. Polar coordinate interpolation cancel
1383 Integer 384 G code for an interpolation rigid tapping cycle
1384 Integer 380 G code for canceling an interpolation rigid tapping cycle
1390 Integer 1 Output format of canned cycle R code
0 : absolute,
1 : incremental
1391 1
characters
K Canned cycle repetitive code
1392 2
characters
RR
II
Address specifying the difference in radius of the thread for a multiple thread
cutting cycle (High order: 5710, low order 5E00)
1393 2
characters
PP
KK
Address specifying the thread height for a multiple thread cutting cycle (High
order: 5710, low order 5E00)
1394 2
characters
QQ
DD
Address specifying the depth of the first cut for a multiple thread cutting cycle
(High order: 5710, low order 5E00)
1395 2
characters
PP
AA
Address specifying a tool angle for a multiple thread cutting cycle (High order:
5710, low order 5E00)
1396 2
characters
PP
PP
Address specifying the cutting method for a multiple thread cutting cycle
(High order: 5710, low order 5E00)
1397 2
characters
RR
RR
Address specifying a finishing allowance for a multiple thread cutting cycle
(High order: 5710, low order 5E00)
NOTE
Parameter numbers other than listed above may also
appear on the CRT. These parameters are employed the
system.
Don’t change them.
