Automatically entered comments are as follows. Each type of machining
has characteristic contents.
Machining type Output comment
Center drilling CENTER DRIL.
Drilling DRIL.
OD roughing ROUGH. OF OUT.
ID roughing ROUGH. OF IN.
OD semi–roughing S–FIN. OF OUT.
ID semi–roughing S–FIN. OF IN.
OD finishing FIN. OF OUT.
ID finishing FIN. OF IN.
Grooving/necking GROV. OR NECK.
Threading THREAD.
Groove roughing ROUGH. OF GROOVE
Groove finishing FIN. OF GROOVE
Reamer REAMER
Tap TAP
Machining type Output comment
C axis center drilling C–CENTER DRILL.
C axis drilling C–DRILLING
C axis tapping C–TAPPING
C axis grooving C–GROOVING
Face milling C–FACE MILLING
Side milling C–SIDE MILLING
Y axis center drilling Y–CENTER DRILL.
Y axis drilling Y–DRILLING
Y axis tapping Y–TAPPING
Y axis pattern Y–PATTERN
Y axis contouring Y–CONTOUR
Sub cycle SUB CYCLE
Cut off CUT OFF
Bar feed BAR FEED
NOTE
It is not possible to output the process name comment when
NC format is outputted in main/sub format.
