Conversional Automatic Programming (CAP) Operators manual Page 577

Operators manual
AUTOMATIC PROCESS
DETERMINATION FUNCTION
B–61804E–2/05
1. OUTLINE
316
CAUTION
The tools to be used are determined from tooling data and
tool data.
NOTE
1 The end surface and outer surface can be machined in
separate processes for outer surface machining.
2 For the outer and inner surface machining processes,
inverse processes can also be automatically determined (B
option for the automatic process determination function).
3 The following processes cannot be automatically
determined. Enter data manually.
– Reaming
– Tapping
4 Auxiliary machining processes cannot be automatically
determined.
5 Multiple processes can be specified for drilling (only for
turning) to create multitiered parts (B option for the
automatic process determination function).
6 The cutting–off process cannot be determined when system
parameter 140 is 0.
