Conversional Automatic Programming (CAP) Operators manual Page 673

Operators manual
B–61804E–2/05
A. SETTING DATA,
SYSTEM PARAMETER, MTF
APPENDIX
23
Parameter
No.
RemarksDescription
Initial
value
Format
0366 Real number Undefined Can’t use. (Don’t change the data.)
0367 Real number
2. mm specification
Tool direction clearance of C–axis
grooving CD and notching clearance of
0.08 inch specification
C–axis grooving C1.
Unit: mm or inch
0368 Real number
0.5 mm specification
Finishing allowance in C–axis front
notching
inch specification
notching
Unit: mm or inch
0369 Real number Undefined Can’t use. (Don’t change the data.)
0370 Real number 2000. Max. rpm of tool (rpm) C–axis/
Y–axis
0371 Real number
1.0
Extension amount for approach/escape along a tangent line or
circle in C
–
axis milling or Y
–
axis contouring
0.1
circle
in
C
–
axis
milling
or
Y
–
axis
contouring
0372 Real number 0.2 Cutting rate toward a diameter for C–axis face milling
For C–axis
machining
0373 Real number
0.5 mm specification
Finishing allowance of C–axis face milling
(in the Z axis direction)
machining
0.02 inch specification
(in
the
Z
axis
direction)
Unit: mm or inch
0400 0, 1
designation (8 bits)
00100100 Y–axis center drilling process parameter
Bit 1 Coolant
0 : Not used
1 : Used
Bit 2 Cancellation of tool compensation
0 : Not output
1 : Output
Bit 3,4 Approach
00: Simultaneous 1 axis
01: Simultaneous 2 axis
10: Simultaneous 3 axis
11: Simultaneous 4 axis
Bit 5,6 Return relief
00: Simultaneous 1 axis
01: Simultaneous 2 axis
11, 10: Simultaneous 3 axis
Bit 7 The prompt relating to the passing point is:
0 : Not displayed.
1 : Displayed.
7 6 5 4 3 2 1 0
0
Bit
For Y–axis
machining
0401 0, 1
designation (8 bits)
00100100 Y–axis drilling process parameter
(refer to the parameter No.400)
0402 0, 1
designation (8 bits)
00100100 Y–axis tapping process parameter
(refer to the parameter No.400)
0403 0, 1
designation (8 bits)
00100100 Y–axis pattern machining process parameter
(refer to the parameter No.400)
0404 0, 1
designation (8 bits)
00100100 Y–axis contouring process parameter
(refer to the parameter No.400)
