Conversional Automatic Programming (CAP) Operators manual Page 661

Operators manual
B–61804E–2/05
A. SETTING DATA,
SYSTEM PARAMETER, MTF
APPENDIX
11
Parameter
No.
RemarksDescription
Initial
value
Format
0012 Real number
1000. mm specification
System variable (Do not change the setting
by yourself )
12. inch specification
by
yourself
.
)
0013 Real number 0 Setting of display time of initial graphic
0 : Initial graphic display is always displayed.
n : Initial graphic display is cleared, if its display lasts n second.
0014 Real number 6.4 Move amount of cursor at a time when expansion or
contraction is done by DRAWING RANGE key. This value is
specified by a multiplier of 1.6 mm inclusive.
0015 0, 1
designation (8 bits)
00010001 Set the I/O unit of family program, material file, and tooling file.
Bit 0 Input unit
Bit 4 Output unit
0 : Memory cassette
1 : Submemory
7
0
6
0
5
0
4 3
0
2
0
1
0
0Bit
0016 Character Undefined Set the name of material file to be automatically loaded. Within 15
characters.
0017 Character Undefined Set the name of tooling information to be automatically loaded. Within 15
characters.
0018 Character Undefined Can’t use. (Don’t change the data.)
0019 0, 1
designation (8 bits)
00000000 Setting of CRT when a figure is drawn vertically
0 : Horizontal drawing display.
1 : Vertical drawing display.
Bit 0 Setting for menu No.4, 5 and 6.
Bit 1 Setting for menu No.1, 2, 4, 5 and 6
7
0
6
0
5
0
4
0
3
0
2
0
1 0Bit
0020 0, 1
designation (8 bits)
00000000 Can’t use. (Don’t change the data.)
0049 0, 1
designation (8 bits)
00000000 Single step of bar feed process
0 : Not stopped
1 : Stopped
Bit 0 Process start
Bit 1 Just before approach
Bit 2 Just before escape
7
0
6
0
5
0
4
0
3
0
2 1 0Bit
0050 0, 1
designation (8 bits)
00000000 Single step of center drilling process
(Refer to parameter No.49)
0051 0, 1
designation (8 bits)
00000000 Single step of drill process, reamer process and tapping
process
(Refer to parameter No.49)
0052 0, 1
designation (8 bits)
00000000 Single step of rough cutting process
(Refer to parameter No.49)
