Series 16i/18i/21i/160i/180i/210i-Model A Startup Guide Page 20

Startup Guide
1 - 16 16
i
/18
i
/21
i
Startup Guide -
May 2000
B-63003EN-2/01
1
Connecting the Control to the Spindle Amplifiers
We will discuss the serial spindle connection in this startup guide. If your setup involves an
analog spindle, please refer to:
Chapter 7.8 in the 16i /18i / 160i / 180i - Model A Connection Manual
Chapter 6.2 in the 21i / 210i - Model A Connection Manual
Serial Spindle Connection
To connect a serial spindle, follow these steps:
1
.
Locate the cable you will use to connect the control to
the spindle amplifier. This cable could be one of the
following cables:
LX660-2077-T203/L200R0 0.2 m length
LX660-2077-T203/L300R0 0.3 m length
LX660-2077-T203/L500R0 0.5 m length
LX660-2077-T203/L1R003 1.0 m length
LX660-2077-T203/L2R003 2.0 m length
LX660-2077-T203/L3R003 3.0 m length
LX660-2077-T203/L4R003 4.0 m length
LX660-2077-T203/L5R003 5.0 m length
LX660-2077-T203/L6R003 6.0 m length
LX660-2077-T203/L7R003 7.0 m length
LX660-2077-T203/L8R003 8.0 m length
LX660-2077-T203/L10R03 10.0 m length
2
.
Insert one end of this cable into the connector labeled
JA41
on the back of the control.
3
.
Insert the other end into the connector labeled
JA7B
on the spindle amplifier module.
4. You can connect a second spindle amplifier module by running a cable from connector
JA7A
on the first amplifier to
JA7B
on the second amplifier. You can use one of the
cables whose part numbers are listed in step 1.
Note
There are many different pulse coder connection possibilities for the GE
Fanuc α series spindle motors. The following example describes how to
connect a serial spindle if you are using the pulse generator built into the
motor. If you are using a different pulse coder configuration, please refer to
Chapter 9.3.4 in the GE Fanuc Control Motor Amplifier
α
αα
α
series Description
Manual.
