Startup Guide -

May 2000

B-63003EN-2/01

GE Fanuc Cables Description Application

LX660-8077-T213/L3R003 3m

LX660-8077-T213/L4R003 4m

LX660-8077-T213/L5R003 5m

LX660-8077-T213/L6R003 6m

LX660-8077-T213/L7R003 7m

LX660-8077-T213/L8R003 8m

LX660-8077-T213/L10R03 10m

LX660-8077-T213/L12R03 12m

LX660-8077-T213/L16R03 16m

LX660-8077-T213/L18R03 18m

LX660-8077-T213/L20R03 20m

LX660-8077-T213/L22R03 22m

LX660-8077-T213/L24R03 24m

LX660-8077-T213/L27R03 27m

LX660-8077-T213/L30R03 30m

Servo Power

Supply Cable

Power cable for Connection

between Alpha amplifier

and A 1 – A 2 straight type

with brake

One of the ends of this cable has four wires which connect to the α series servo

amplifier’s terminal strip. Connect the four wires to the corresponding amplifier

terminals labeled

, and

Ground

. The bottom terminal block on the servo

amplifier module which consists of these connectors is labeled

TB2

on Figure 1-8.

Note

Axis numbers are designated by the letters L (1

axis), M (2

axis), and

N (3

axis). For a motor connected to the second axis, the power cables

would be attached to amplifier terminals

, and

Ground

Remove the plastic cap protecting the motor’s connector and attach the other end of

the cable to the motor. The motor cables are keyed and can only be properly attached

to the proper motor connection point.
