Interface Between Servo Amplifier and Servo Software
In order to set FSL, there are five conditions which have to be satisfied. It can be fairly
confusing, and for a startup application, it is only important that the parameter is not set
incorrectly. An easy way to set this parameter is to follow these guidelines:
1
.
If the axis number is odd, enter “0”. The axis number is what you entered in parameter
1023.
2
.
If the axis number is even, enter “1”.
1905 FSL
X
00000000
Z
00000001
C
00000000
Address Conversion Table Values for Slaves
A slave is just a device such as a servo amplifier or pulse module which is connected to the
control via the FSSB. A maximum of ten slaves can be assigned to the control. A two-axis
amplifier has two slaves, while a three-axis amplifier has three slaves and so on.
There are ten consecutive parameters and each one is assigned to one slave. This means that
parameter 1910 is the address conversion table value for slave one, and parameter 1919 for slave
ten. In our example, we have three slaves.
Follow this procedure when connecting amplifiers (keep in mind that this applies to parameters
1910~1919):
1
.
When the slave is an amplifier
, just subtract 1 from the value in parameter
1023 for each axis.
2
.
When there is no slave, set the parameter to 40.
1910 0
1911 1
1912 2
1913 40
1914 40
1915 40
1916 40
1917 40
1918 40
1919 40
