Series 16i/18i/21i/160i/180i/210i-Model A Startup Guide Page 25

Startup Guide
B-63003EN-2/01 Chapter 1 Assembling the 16i/18i/21i 1 - 21
1
GE Fanuc Cables Description Application
LX660-8077-T202/L3R003 3m
LX660-8077-T202/L4R003 4m
LX660-8077-T202/L5R003 5m
LX660-8077-T202/L6R003 6m
LX660-8077-T202/L7R003 7m
LX660-8077-T202/L8R003 8m
LX660-8077-T202/L10R03 10m
LX660-8077-T202/L12R03 12m
LX660-8077-T202/L16R03 16m
LX660-8077-T202/L18R03 18m
LX660-8077-T202/L20R03 20m
LX660-8077-T202/L22R03 22m
LX660-8077-T202/L24R03 24m
LX660-8077-T202/L27R03 27m
LX660-8077-T202/L30R03 30m
Servo Power
Supply Cable
Power cable for Connection
between Alpha amplifier
and A 12 – A 22
straight connector
size 22-22
LX660-8077-T203/L3R003 3m
LX660-8077-T203/L4R003 4m
LX660-8077-T203/L5R003 5m
LX660-8077-T203/L6R003 6m
LX660-8077-T203/L7R003 7m
LX660-8077-T203/L8R003 8m
LX660-8077-T203/L10R03 10m
LX660-8077-T203/L12R03 12m
LX660-8077-T203/L16R03 16m
LX660-8077-T203/L18R03 18m
LX660-8077-T203/L20R03 20m
LX660-8077-T203/L22R03 22m
LX660-8077-T203/L24R03 24m
LX660-8077-T203/L27R03 27m
LX660-8077-T203/L30R03 30m
Servo Power
Supply Cable
Power cable for Connection
between Alpha amplifier
and A 12 – A 22
elbow connector
size 22-22
LX660-8077-T204/L3R003 3m
LX660-8077-T204/L4R003 4m
LX660-8077-T204/L5R003 5m
LX660-8077-T204/L6R003 6m
LX660-8077-T204/L7R003 7m
LX660-8077-T204/L8R003 8m
LX660-8077-T204/L10R03 10m
LX660-8077-T204/L12R03 12m
LX660-8077-T204/L16R03 16m
LX660-8077-T204/L18R03 18m
LX660-8077-T204/L20R03 20m
LX660-8077-T204/L22R03 22m
LX660-8077-T204/L24R03 24m
LX660-8077-T204/L27R03 27m
LX660-8077-T204/L30R03 30m
Servo Power
Supply Cable
Power cable for Connection
between Alpha amplifier
and A 30 – A 40
straight connector
size 24-10
