Other Parameters on the Servo Setting Screen
We will continue now to set the remaining parameters on the servo setting screen. Here is a
brief description of each parameter and how to set them:
Initial Set Bits
Bit #1 in this sequence (the second bit from the right) must be set to zero for each axis before
cycling power. Upon power-up, this tells the CNC to look at the
MOTOR ID NO
. which you just
entered and to copy all parameters for that specific motor from the servo ROM into memory.
The control will automatically set bit #1 and bit #3 to one after initialization.
For most applications, you can just go ahead and set all eight bits to zero (it’s much easier to
remember). However, there may be instances where you would want to scale back the number
of feedback pulses by setting bit # 0 to one. If you need to do this, please refer to Chapter 2 in
the GE Fanuc
α
αα
α
Series Servo Motor Parameter Manual (publication no. B-65150E) for more
information.
Direction Set
This parameter specifies the direction in which the motor rotates. It can only take on the
following two values:
111 clockwise as viewed from the pulse coder
-111 counterclockwise as viewed from the pulse coder
Ex. Set all three axes to clockwise rotation. Enter 111 for all three axes on the servo
setting screen next to
DIRECTION SET
.
Velocity Pulse No.
For most applications, set this parameter to 8192. If you have a situation where you need to set
bit #0 of the
INITIAL SET BITS
to one, you should enter the value 819. Again, please refer to
Chapter 2 in the GE Fanuc
α
αα
α
Series Servo Motor Parameter Manual for more information.
Position Pulse No.
This parameter should be set to 12500 if you are using the built-in motor encoder. If you are
using separate feedback, please refer to Chapter 2 in the GE Fanuc
α
αα
α
Series Servo Motor
Parameter Manual for the correct parameter setting.
