Series 16i/18i/21i/160i/180i/210i-Model A Startup Guide Page 24

Startup Guide
1 - 20 16
i
/18
i
/21
i
Startup Guide -
May 2000
B-63003EN-2/01
1
1
.
Find the cable which connects the motor to the servo amplifier. Look up your cable
part on the table below:
Table 1 - 3. Cross reference of motor power cables
GE Fanuc Cables Description Application
LX660-8077-T200/L3R003 3m
LX660-8077-T200/L4R003 4m
LX660-8077-T200/L5R003 5m
LX660-8077-T200/L6R003 6m
LX660-8077-T200/L7R003 7m
LX660-8077-T200/L8R003 8m
LX660-8077-T200/L10R03 10m
LX660-8077-T200/L12R03 12m
LX660-8077-T200/L16R03 16m
LX660-8077-T200/L18R03 18m
LX660-8077-T200/L20R03 20m
LX660-8077-T200/L22R03 22m
LX660-8077-T200/L24R03 24m
LX660-8077-T200/L27R03 27m
LX660-8077-T200/L30R03 30m
Servo Power
Supply Cable
Power cable for Connection
between Alpha amplifier
and B 1 – B 6
A 3 – A 6
straight connector
LX660-8077-T201/L3R003 3m
LX660-8077-T201/L4R003 4m
LX660-8077-T201/L5R003 5m
LX660-8077-T201/L6R003 6m
LX660-8077-T201/L7R003 7m
LX660-8077-T201/L8R003 8m
LX660-8077-T201/L10R03 10m
LX660-8077-T201/L12R03 12m
LX660-8077-T201/L16R03 16m
LX660-8077-T201/L18R03 18m
LX660-8077-T201/L20R03 20m
LX660-8077-T201/L22R03 22m
LX660-8077-T201/L24R03 24m
LX660-8077-T201/L27R03 27m
LX660-8077-T201/L30R03 30m
Servo Power
Supply Cable
Power cable for Connection
between Alpha amplifier
and B 1 – B 6
A 3 – A 6
elbow connector
size 18-10
