B-63003EN-2/01 2 - 1
Chapter
Configuring the 16i/18i/21i
The GE Fanuc
i
-series CNC is a high-performance control with an extensive set of features and
can be adapted to many different lathe and machining center applications. You can easily make
adjustments to alter or improve your system using data registers in the control.
These data registers are called parameters.
Although the control contains several hundred parameters, only a small number of these must
be set for most applications. This chapter explains how to set these basic parameters so that
you can get the motor up and running.
For parameter information not contained in this chapter, please refer to the appropriate manual
(s):
16i/18i/160i/180i - Model A Parameter Manual (publication no. B-63010EN)
21i/210i - Model A Parameter Manual (publication no. B-63090EN)
α
αα
α
Series AC Servo Motor Parameter Manual (publication no. B-65150E)
2
Previous page
Next page
