Ref. Counter
This quantity is defined as the number of detection units per revolution of the motor. That
probably gets to be confusing, so here is an easier way to consider this value. The reference
counter is the actual pulse resolution of the motor scaled down by the factor
N
M
calculated
previously. Continuing with the example in this section, we can calculate the reference counter
as follows:
1,000,000 feedback pulses
1 motor revolution
pulses per revolution×=
1
20
50 000,
On the servo setting screen, you would enter 50,000 as the parameter value for
REF. COUNTER
.
Putting It Together
If we enter parameters into the servo setting screen using values we obtained in the examples
above, it should look like the screen below. For simplicity’s sake, identical values have been
used for both the X and Z axes. Keep in mind, however, that you must follow the servo
parameter setting procedure for each axis separately.
Please turn off the power to the control before moving on to the next chapter.
SERVO SETTING
X-AXIS Z AXIS
INITIAL SET BITS 00000000 00000000
MOTOR ID NO. 7 7
AMR 00000000 00000000
CMR 20 20
FEEDGEAR N 1 1
(N/M) M 2 2
DIRECTION SET 111 111
VELOCITY PULSE NO. 8192 8192
POSITION PULSE NO. 12500 12500
REF. COUNTER 50000 50000
Figure 2 - 5. Servo setting screen complete with parameters
Remember to power down the control before moving on!
