This connection consists of two lines. Connect the +24V line to pin 1 of the
connector. Connect the 0V line to pin 2 of the connector.
3
.
When you have completed wiring the connector, insert it into the slot labeled
CP32
on
the face of the I/O module.
4
.
On the other end, connect the +24V line (pin 1) to the positive terminal at the power
source and the line labeled 0V (pin 2) to the common of the power source.
Note
Even though the control and operator’s panel connection unit also require
24V DC power, we recommend that you use a separate power supply just for
the I/O modules. There are strict timing requirements which define how the
control and I/O modules have to be powered on and off. In order to prevent
CNC errors, you should use a relay to connect the switching device on the
operator’s panel to the I/O power supply.
