The GE Fanuc Operator’s Panel for i-series Controls
The GE Fanuc Operator’s Panel is identified by GE Fanuc, see Chapter 1 page 8
.
Follow these
steps to connect the operator’s panel (see Figure 1-15 on the previous page for a complete
connection diagram for the operator’s panel). Note that all of the supplied devices are wired
except for the emergency stop push-button. The emergency stop wiring will differ from
system to system and this must be done by the machine tool builder.
1
. In order to connect the operator’s panel, you must first
physically mount the operator’s panel connection unit
onto the back of the operator’s panel.
2
.
If you carefully look at the connection board, it has five screw holes - three along one
edge and two along the other edge. This board can only be mounted onto the back of
the operator’s panel in one way. Remove the screws from the back of the operator’s
panel, line up the holes, and screw in to secure the board.
3
.
Now, in order to
connect the operator’s panel connection unit
to the I/O link, l
ocate the I/O link cable identified by GE Fanuc part :
Specification Length Remarks Application
LX660-2007-T010/L500R0 0.5 m
LX660-2007-T010/L1R003 1 m
LX660-2007-T010/L2R003 2 m
LX660-2007-T010/L3R003 3 m
LX660-2007-T010/L4R003 4 m
LX660-2007-T010/L5R003 5 m
LX660-2007-T010/L6R003 6 m
LX660-2007-T010/L7R003 7 m
LX660-2007-T010/L8R003 8 m
LX660-2007-T010/L10R03 10 m
Connector
A02B-0120-K302
2
nd
Connector
A02B-0120-K302
Cable material
LX66L-0002-0284
Cell Controller – I/O unit
JD1A – JD1B
LX660-2007-T013/L500R0 0.5 m
LX660-2007-T013/L1R003 1 m
LX660-2007-T013/L2R003 2 m
LX660-2007-T013/L3R003 3 m
LX660-2007-T013/L4R004 4 m
LX660-2007-T013/L5R003 5 m
LX660-2007-T013/L6R003 6 m
LX660-2007-T013/L7R003 7 m
LX660-2007-T013/L8R003 8 m
LX660-2007-T013/L10R03 10 m
Connector
A02B-0120-K302
2
nd
Connector
A02B-0120-K302
Cable material
LX66L-0002-0283
Cable material with
PUR sheath
Cell Controller – I/O unit
JD1A – JD1B
