B-63003EN-2/01 4 - 1
Chapter
Powering Up the Entire System
Until now, we have set parameters and edited the ladder but we have done so by only powering-
up the control. Now we are finally ready to set the last group of parameters which will allow you
to bring up the other crucial element in our control system: the servo amplifiers.
The servo amplifiers are connected to the control by an optical cable called the Fanuc Serial
Servo Bus (FSSB). As you might have guessed, there are parameters related specifically to the
FSSB optical link between the control and the servo drives. This next section will discuss how to
go about correctly setting the FSSB parameters.
Note
The examples given in this section are a continuation of those from Chapter 2.
If you are using a 3-axis configuration (it doesn’t matter if you have a 16
i
, 18
i
,
or 21
i
), you can just enter the parameter values exactly as they appear in this
manual. If you are running more than three axes, make sure you follow the
directions carefully.
For parameter settings of different setup configurations, (such as a separate feedback device),
please refer to:
16i / 18i / 160i / 180i - Model A Parameter Manual (publication no. B-63010EN)
21i / 210i - Model A Parameter Manual (publication no. B-63090EN)
4
Previous page
Next page
