Section 1 Setting the Initial Parameters
Once you have confirmed that the supplied cables have been attached to the appropriate
connectors, you can go ahead and power up the control by pushing the ON button on the
operator’s panel. When the control comes up, you will see a list of alarm messages displayed in
a rectangle on the right hand side of the LCD. Ignore these for now.
After a brief overview of parameters and how to enter their values, you will begin by just
setting the most basic parameters as well as those necessary to eliminate the alarms.
Once you have successfully gone through the Startup Guide and turned the motors, you can
go back and enter the parameters specific to your application.
Types of Parameters
There are two types of parameters for the control:
1
.
Bit-type parameters - These are basically ON/OFF switches which enable or disable
a certain function. They can only be given the binary values 0 and 1.
Ex.
0000 SEQ INI ISO TVC
00000100
parameter #
bit #7 ••••••bit #0
Bit-type parameters will be illustrated in this way throughout this manual. The text
above certain bits represents the three character name designated to that certain
parameter. In this example, parameter 0000.2 (the value after the decimal is the bit #)
has the value 1.
2
.
Word-type parameters - These are used for parameters requiring a numerical value.
Ex.
1410 DRY RUN RATE 5000
