Series 16i/18i/21i/160i/180i/210i-Model A Startup Guide Page 52

Startup Guide
B-63003EN-2/01 Chapter 2 Configuring the 16i/18i/21i 2 - 11
2
Determining the Motor ID Number
For proper setup, the control needs information that is provided by the model number of each
motor. The motor model number is located on a tag affixed to the motor and should look like
this:
A06B-xxxx-Byzz
these four digits determine the motor ID
To find the correct value for the parameter labeled
MOTOR ID NO
., simply match the motor
identifier which you read off the motor tag to the motor type in the right column. Enter this
number on the servo setting screen as your
MOTOR ID NO
parameter. Do this for each axis.
Let’s say for example that your motor is labeled
A06B-0121-B072.
Looking up
0121
in the
table, we can determine the motor type to be 7.
Once again, the alarm messages screen pops up with an alarm:
000 PLEASE TURN OFF POWER
To get back to the parameter screen, press [SYSTEM] followed by (PARAM).
Table 2 - 1. Motor Type Definition
xxxx Motor
Type
xxxx Motor
Type
xxxx Motor
Type
0013 13 0152 22 0186 107
0101 35 0153 23 0331 39
0102 36 0157 30 0332 40
0105 33 0158 29 0333 41
0106 34 0161 24 0371 61
0113 13 0162 25 0372 46
0121 7 0163 26 0374 84
0123 15 0165 100 0376 97
0126 8 0166 101 0377 98
0127 16 0169 108 0410 90
0128 17 0171 1 0411 91
0141 9 0172 2 0412 92
0142 18 0176 3 0413 93
0143 19 0177 4 0561 56 or 68
0145 10 0178 5 0562 57 or 69
0146 27 0182 104 0564 58 or 70
0147 20 0183 105 0571 59
0148 21 0185 106 0572 60
0151 28
