Series 16i/18i/21i/160i/180i/210i-Model A Startup Guide Page 70

Startup Guide
4 - 2 16
i
/18
i
/21i Startup Guide -
May 2000
B
-63003EN-2/01
4
Setting FSSB parameters
Now we will go ahead and describe how to set the last grouping of parameters. When you are
finished with this section, you should be able to get the servo motors turning.
Servo Axis Number
This is the parameter which tells the control which motor is turning which axis. Back in chapter
2, we set this parameter value to -128 for all axes in order to get rid of an alarm. Now we need to
assign axis numbers to each motor. The axis numbers are assigned as follows:
1
.
If you have only one servo amplifier, the axis number is the same as the number of the
connector where you have your motor feedback cable plugged in. For example, if your
X-axis feedback is plugged in the slot
ENC1 JF1
, then you would enter the value “1” for
your servo axis number.
2
.
The axis number on the second amplifier would start where you ended on the first. Let’s
say that we have three axes and two amplifiers. Two axes were plugged into the first
amplifier and one in the second. Even though the one axis in the second amplifier plugs
into slot
ENC1 JF1
, it would be assigned the value “3” because it is the third axis.
In this 3-axis example, your parameter values should be changed to these:
1023 SERVO AXIS NUM. X 1
Z2
C3
Now, you will notice that the alarm messages screen pops up with this message:
000 PLEASE TURN OFF POWER
Just as we did in chapter 2, simply ignore this alarm and just cycle the power once when you have
set all of the basic parameters. To get back to the parameter screen, press [SYSTEM] followed by
(PARAM).
The FSSB Setting Mode
Set FMD to one. This means that you will manually enter values for parameter numbers 1023,
1905, 1910~1919, 1936, and 1937 (these are the FSSB parameters).
1902 FMD
00000001
