FAPT Ladder-II Operators manual Page 417

Operators manual
FAPT LADDER-II
SUPPLEMENTARY OPERATOR’S
MANUAL
01 99.02.26 Ino New making B-66184EN/02-6
EDIT DATE DESIG.
DESCRIPTION
14/26
TITLE
DRAW.NO.
SHEET
CUST.
[Print Range] Group Set the range of the print. In default, [All] is checked.
[All] All are printed.
[Net No.] Specify the range of the net, which you want to print.
[Page No.] Specify the range of the page, which you want to
print.
[Print Program] Group Set printing Ladder Program. In default, [All] is
checked.
[All] All are printed.
[Unit] Print specified subprogram. Input the subprogram
name
which you want to print, or select the subprogram
name
from combo box.
[Page Feed] Group Specify form feed.
[Page Feed(Sub Program)] Specify the presence of form feed for each subprogram.
Default is no form feed.
[Details…] Button Specify a detailed setting of the Ladder Diagram print.
The Ladder Diagram detailed setting dialog is
displayed
when selecting. Refer to “(2) Ladder Diagram print
option
detailed screen” for details.
[Preview] Button Save the print option setting and do preview of the
Ladder Diagram. This button is effective when any
print
item is selected.
[OK] Button Save the print option setting and end the print option
setting dialog.
[Cancel] Button Discontinue the print option setting and end the print
option setting dialog.
[Help] Button Refer to help of the Ladder Diagram print option.
