2. PARAMETERS FOR THE SPEED AND LOOP GAIN SWITCH
13
2
PARAMETERS FOR THE SPEED AND LOOP GAIN SWITCH
#7 #6 #5 #4 #3 #2 #1 #0Address
16050 KLV PCT CT2 KLC NCT N3S PCF G0F
Data type: Bit
G0F For a rapid traverse command (G00), the X–axis or Y–axis
rapid traverse feedrate is set to the value:
0: Specified in the parameter.
1: Specified by the F code.
The maximum feedrate of the F command is limited to the rapid
traverse feedrate in the parameter. KLV (No. 16050, #7) and
LPG (No. 16051, #4) are valid.
PCF The X–axis or Y–axis movement mode is selected for the
following blocks:
(1) Movement to each punch point with the pattern function
(G26, G76, G77, G78, etc.)
(2) Operation in automatic repositioning (G75)
(3) Movement to the first punch point with the nibbling
function (G68, G69, and M code)
0: Rapid traverse is executed.
1: For G00, rapid traverse is executed. For G01, G02, or G03,
linear interpolation cutting feed is executed.
N3S During nibbling, three–stage switching for constant positioning
time control for the X– and Y–axes is:
0: Disabled
1: Enabled
When this parameter is set to 1, parameters No. 16800 to 16827
are also used.
NCT Constant control of positioning time is:
0: Always enabled.
1: Enabled only when the nibbling command is executed.
This parameter is valid when the PCT bit (bit 6 of parameter
16050) is set to 1.
KLC When rapid traverse is executed in automatic operation, the
function to change the time constant and C–axis rapid traverse
feedrate among three levels according to the positioning
angleis:
0: Invalidated.
1: Validated. See the descriptions of parameters 16140 to
16147.
CT2 In constant control of the positioning time, the times specified
in parameters 16095 to 16102 are:
0: Not changed.
1: Doubled.
