Series 16i/18i/160i/180i - PB Parameter manual Page 75

Parameter manual
B–63690EN/01
11. SPEED AND SERVO PARAMETER
SWITCHING PARAMETERS
69
Address
16871 Rapid traverse time constant for first stage
16872 Rapid traverse time constant for second stage
16873 Rapid traverse time constant for third stage
16874 Rapid traverse time constant for fourth stage
16875 Rapid traverse time constant for fifth stage
16876 Rapid traverse time constant for sixth stage
16877 Rapid traverse time constant for seventh stage
Data type: Word axis
Units of data: msec
Valid data range: 8 to 4000
Set the rapid traverse time constant for each positioning distance, for each
axis.
These parameters are valid for those axes for which bit 7 (KL2j) of
parameter No. 16844 is set to 1.
Address
16878
Positioning time for first stage
(when rapid traverse override is 100% or 75%)
16879
Positioning time for second stage
(when rapid traverse override is 100% or 75%)
16880
Positioning time for first stage
(when rapid traverse override is 50% or 25%)
16881
Positioning time for second stage
(when rapid traverse override is 50% or 25%)
Data type: Byte axis
Units of data: msec
Valid data range: 8 to 248
When using constant positioning time control, set the positioning time for
the first and second stages, for each axis.
These parameters are valid for those axes for which both bits 7 (KL2j) and
6 (PT2j) of parameter No. 16844 are set to 1.
