8. PARAMETERS (1) FOR THE SAFETY ZONE
B–63690EN/01
50
8
PARAMETERS (1) FOR THE SAFETY ZONE
#7 #6 #5 #4 #3 #2 #1 #0Address
16500 YSF SAT SF0
Data type: Bit
SF0 The safety zone of type:
0: A is used.
1: B is used.
NOTE
When type B is used, punching is inhibited in punching
mode and entry is inhibited in laser mode.
SAT When punching is inhibited in the safety zone, the block in
which a T command is specified is checked:
0: In advance.
1: After the FIN signal to complete the T command has been
received.
YSF When a safety zone check is executed, the inhibited area along
the Y axis extends from the values set in parameters 16507,
16510, 16513, and 16516:
0: In the negative direction.
1: In the positive direction.
#7 #6 #5 #4 #3 #2 #1 #0Address
16501 SZ8 SZ7 SZ6 SZ5 SZ4 SZ3 SZ2 SZ1
Data type: Bit
SZj When a safety zone check is executed, in the #j (j=1 to 8) area,
0: An entry is inhibited.
1: Punching is inhibited.
NOTE
To use SZ5 to SZ8, the safety zone area extension function
is necessary.
