Series 30i-MODEL A, Tool center point control for 5-axis machining Additional Manual Page 14

Additional Manual
A-79348E
Title
Draw
No.
12/88
page
FANUC Series 30i-MODEL A
Tool center point control
for 5-axis machining
Ed. Date Design Description
Date Jan.16.’04 Design. Apprv.
CAUTION
1 Only arc radius R can be specified. (The distance
from the start point to the center of the arc cannot
be specified using I, J, and K.)
2 A round circle (the start point and end point are the
same) cannot be specified.
3 Any command that does not move the tool center
point with respect to the workpiece (one that moves
the rotary axes only) must be executed in G00 or
G01 mode.
4 See the CAUTION box for "Positioning and linear
interpolation for tool center point control (type 2)".
