FANUC Series 30i-MODEL A
Tool center point control
for 5-axis machining
Ed. Date Design Description
Date Jan.16.’04 Design. Apprv.
- In the case of a mixed type machine
Explanations are given below assuming a mixed type machine configuration
that has one table rotation axis (which turns around the X-axis) and one tool
rotation axis (which turns around the Y-axis). (See Fig. 1.1 (l).)
If linear interpolation is specified for the X-, Y-, and Z-axes on the
programming coordinate system and if the rotary axis that moves the rotation
table and the tool rotation axis are specified (in the case of type 1) or the tool
direction is specified (in the case of type 2), control is exerted in such a way
that the tool center point moves along a specified straight line with respect to
the table (workpiece) as the rotation table and tool rotate.
Also, speed control is exerted so that the tool center point moves at the
specified speed with respect to the table (workpiece).
Example)
When type 1 is selected and the coordinate system fixed on the table is used
as the programming coordinate system
(Parameter WKP (No.19696#5) = 0):
O300 (Sample Program3) ;
N1 G00 G90 A0 B0 ;
N2 G55 ; Prepares the programming coordinate
system.
N3 G43.4 H01 ; Starts tool center point control.
H01 is the tool compensation number.
N4 G00 X200.0 Y150.0 Z20.0 ; Moves to the start point.
N5 G01 X5.0 Y5.0 Z5.0 A60.0 B45.0 F500;
Linear interpolation
N6 G49 ; Cancels tool center point control.
N7 M30;
When type 1 is selected and the workpiece coordinate system is used as the
programming coordinate system
(Parameter WKP (No.19696#5) = 1):
O300 (Sample Program3) ;
N1 G00 G90 A0 B0 ;
N2 G55 ; Prepares the programming coordinate
system.
N3 G43.4 H01 ; Starts tool center point control.
H01 is the tool compensation number.
N4 G00 X200.0 Y150.0 Z20.0 ; Moves to the start point.
N5 G01 X5.0 Y48.170 Z-79.772 A60.0 B45.0 F500;
Linear interpolation
N6 G49 ; Cancels tool center point control.
N7 M30;
