FANUC Series 30i-MODEL A
Tool center point control
for 5-axis machining
Ed. Date Design Description
Date Jan.16.’04 Design. Apprv.
#7 #6 #5 #4 #3 #2 #1 #0
19696 SUP RFC WKP IA2 IA1
[Input type] Parameter input
[Data type] Bit path
# 0 IA1
0: The first rotation axis is an ordinary rotation axis.
1: The first rotation axis is a hypothetical axis.
If IA1 is 1, set 0 as the controlled-axis number for the first rotation axis
(parameter No. 19681).
Also, set parameter Nos. 19682 to 19685 on the assumption that there is a
rotation axis.
# 1 IA2
0: The second rotation axis is an ordinary rotation axis.
1: The second rotation axis is a hypothetical axis.
If IA2 is 1, set 0 as the controlled-axis number for the second rotation axis
(parameter No. 19686).
Also, set parameter Nos. 19687 to 19690 on the assumption that there is a
rotation axis.
# 5 WKP The programming coordinate system used for tool center point control for
5-axis machining or cutter compensation for 5-axis machining is:
0: The table coordinate system (fixed on the rotary table).
1: The workpiece coordinate system.
NOTE
In cutter compensation for 5-axis machining, WKP
is valid only when TBP(bit 4 of parameter
No.19746) is 1.
# 6 RFC In tool center point control for 5-axis machining, when a command that does
not move the tool center point with respect to the workpiece is issued, the
feedrate of the rotation axis is:
0: The maximum cutting feedrate (parameter No. 1422).
1: A specified feedrate.
# 7 SUP In tool center point control and tool center point control for 5-axis machining,
when a movement at a specified feedrate causes the deviation of the path to
exceed the permissible level:
0: The feedrate is not decreased.
1: The feedrate is decreased so that the deviation of the path is within the
permissible level.
The permissible level is specified in parameter No. 19745.
